Secure Elements
A rich offering of certified turnkey secure elements
built for the highest security standards.
Secure hardware-based cryptography modules and middleware.
Easy integration in any system
Hardware Level
- Rich set of communication interfaces: NFC, I²C, SPI, USB…
- Low cost industry standard or customized packages
- Extended temperature ranges (-40° / +105°C)
Software Level (running in the Host)
- Host-VaultIC communication Drivers
- Host-VaultIC Secure Communication Channel
- Middleware (PKCS#11, Windows CSP, embedded Linux)
- C source code
Crypto and Security functions
- Enc/Dec: AES, 3DES with FIPS approved modes of operation
- Sign: DSA, ECDSA
- Secure communication channel
- Key Establishment
- FIPS approved Random Number Generators
Product selector guides
| NanoSealRT | |
|---|---|
| Hardware Security | NanoSeal |
| File System | 2Kbits |
| Communication | NFC-ISO15693, NDEF |
| Cryptography | WISeCrypt |
| ECC Signature | v B163 |
| Open Detection | v |
| One-Tap Authentication | v |
| VaultiTrust Provisioning | v |
| Packages | Wafer, CSDisk, CSTop etc. |
| Operating Ranges | [-40°C; +85°C] |
| Status | Sampling |
| datasheet download |
VaultIC184-Sigfox SE  | |
|---|---|
| Hardware Security | CC EAL5+ level |
| Software, Security | Sigfox Verified™ |
| Communication | I2C |
| AES128 | v |
| VaultiTrust Provisioning | v |
| Packages | QFN20 |
| Operating Ranges | [1.62V; 5.5V] [-40°C; +105°C] |
| Status | Production |
| datasheet download |
| VaultIC183 | VaultIC186 | VaultIC155 | |
|---|---|---|---|
| Hardware Security | CC EAL4+ level | CC EAL4+ level | CC EAL4+ level |
| File System | 1.5KB | 1.5KB | 1.5KB |
| Communication | I2C | OWI | NFC-ISO14443B, NDEF |
| Cryptography | ECC up to 283 bits | ECC up to 283 bits | ECC up to 303 bits |
| Certificate | v (+ Host Pub Key Mngt) | v (+ Host Pub Key Mngt) | v |
| Open Detection | x | x | v |
| One-Tap Authentication | x | x | |
| KeyPair Generation | v | v | v |
| VaultiTrust Provisoning | v | v | v |
| Packages | Wafer, DFN6 | Wafer, DFN6 | Wafer, CSDisk, CSTop etc. |
| Operating Ranges | [1,62V; 5,5V] [-40°C; +105°C] | [1,62V; 5,5V] [-40°C; +105°C] | [-40°C; +105°C] |
| Status | Production | Production | Production |
| datasheet download | datasheet download | datasheet download |
| VaultIC420 & 460 | VaultIC405 | VaultIC407 | |
|---|---|---|---|
| Hardware Security | CC EAL5+ | CC EAL5+ | CC EAL5+ level |
| Software, Security | V1.2.14, FIPS140-2 CMVP L3 | V1.0.1, FIPS140-2 CMVP L3 V1.2.1, NIST CAVP | V1.0.2, NIST CAVP |
| File System | 32KB, 112KB | 16KB | 16KB |
| Communication | ISO7816, I2C, SPI, USB, 8 GPIO | I2C, SPI, USB, 5 GPIO | I2C, SPI,5 GPIO |
| ECC | 572 bits | 572 bits | 572 bits |
| DES/3DES | v | v | x |
| AES | v | v with GCM | v with GCM |
| Digital Sign | RSA, DSA, ECDSA | DSA, ECDSA | RSA, DSA, ECDSA |
| Digest | SHA-1 to 512 | SHA-1 to 512 | SHA-1 to 512 |
| Message Authentication | MAC, HMAC | MAC, HMAC, GMAC | MAC, HMAC, GMAC |
| Secure Channel | SCP03 | SCP03 | SCP03, SCP11 |
| Key Agreement | x | ECDH + KDF | ECDH + KDF |
| Real Time Clock | v | x | x |
| RNG, DRBG | v | v | v |
| KeyPair Generation | v | v | v |
| VaultiTrust Provisioning | v | v | v |
| Packages | Wafer, Modules, SOIC8, QFN44 | Wafer, SOIC8, QFN20 | Wafer, SOIC8, QFN20 |
| Operating Ranges | [2.7V; 5.5V] [-40°C; +105°C] | [2.7V; 5.5V] [-40°C; +105°C] | [1.62V; 5.5V] [-40°C; +105°C] |
|
VaultIC420 datasheet download
VaultIC460 datasheet download | VaultIC405 datasheet download | VaultIC407 datasheet download |
